Week 11: Linux Security Architecture In Depth¶

Overview¶

Linux powers the majority of the world's servers, cloud infrastructure, embedded devices, Android smartphones, and supercomputers. Understanding Linux security architecture at a deep level is therefore essential for any OS security professional. This chapter moves beyond surface-level hardening tips to examine why Linux's security model works the way it does, where its structural weaknesses lie, and how modern additions — from Linux Security Modules to systemd sandboxing — address the shortcomings of the original Unix design.

The Linux Security Model: Foundations¶

Linux inherits the Unix principle that everything is a file. Devices (/dev/sda), processes (/proc/1234/), sockets, pipes, and even kernel parameters (/proc/sys/) are exposed as filesystem objects. This unification simplifies the interface — one set of read()/write()/open() system calls governs access to almost everything — but it also means that file permission misconfiguration can expose kernel internals or hardware devices directly to unprivileged users.

The traditional Unix privilege model divides the world into two tiers: processes running as UID 0 (root) and everything else. Root can bypass nearly every access check — reading any file, killing any process, binding to privileged ports, loading kernel modules. This binary model is sometimes called "superuser privilege" and represents a single catastrophic point of failure: any vulnerability that elevates an attacker to root grants unrestricted control over the system.

Key Concept: The traditional root model violates the principle of least privilege. A web server process that only needs to read HTML files should not run as root and therefore should not be able to rewrite /etc/passwd. Linux Capabilities (Chapter 8) partially address this by splitting root privileges into discrete units that can be granted individually.

System Call Interface: The Primary Kernel Boundary¶

Every user-space program interacts with the kernel exclusively through system calls (syscalls). When a process needs to open a file, allocate memory, or send a network packet, it invokes a syscall via a software interrupt or the syscall instruction (x86-64). The CPU transitions from Ring 3 (user mode) to Ring 0 (kernel mode), executes the requested kernel function, and returns to user space.

The system call table (sys_call_table) maps syscall numbers to kernel function pointers. Linux 6.x provides over 400 syscalls. This interface is the most scrutinized boundary in the OS — every syscall is a potential vulnerability if the kernel does not properly validate user-supplied arguments (pointers, lengths, flags).

// Example: how glibc wraps write() into a syscall
// In user space:
ssize_t write(int fd, const void *buf, size_t count) {
    // calls: syscall(SYS_write, fd, buf, count)
    // → triggers Ring 3→0 transition
    // → kernel validates fd, copies buf from user space (copy_from_user)
    // → performs I/O, returns to Ring 3
}

Kernel modules extend the kernel at runtime without rebooting. They can add device drivers, filesystems, or security modules. However, loading a unsigned or malicious kernel module grants the code full kernel privilege — making module signing (CONFIG_MODULE_SIG_FORCE) critical for production systems.

Linux Security Modules (LSM) Framework¶

The LSM framework, introduced in Linux 2.6, provides a set of hooks inserted at security-sensitive points throughout the kernel. When, for example, a process tries to open a file, the kernel calls security_file_open() — an LSM hook. Registered security modules can then enforce additional policy beyond standard DAC (Discretionary Access Control).

Process calls open() → VFS lookup → security_inode_permission() → DAC check → LSM policy check → allow/deny

Key LSM hooks include: - security_inode_permission — file/directory access checks - security_file_open — file open checks (after path resolution) - security_bprm_check — program execution (setuid, label transitions) - security_socket_connect / security_socket_bind — network access

Since Linux 4.15, multiple LSMs can be stacked simultaneously. The major LSMs are:

The /proc Filesystem as Security Intelligence¶

The /proc virtual filesystem exposes kernel and process state as readable files. It is simultaneously a powerful diagnostic tool and an information disclosure risk.

Per-process directories /proc/PID/ contain: - maps — virtual memory layout (reveals ASLR bases if readable) - mem — direct process memory (only readable by same UID or ptrace-capable processes) - environ — environment variables (may contain secrets, API keys) - cmdline — command-line arguments (may include passwords passed as args) - fd/ — open file descriptors (reveals open sockets, pipes) - status — process metadata including UID, GID, capabilities

# Reading /proc to investigate a running process (as root):
cat /proc/$(pgrep sshd)/maps        # reveals memory layout
cat /proc/$(pgrep sshd)/environ | tr '\0' '\n'  # environment variables
ls -la /proc/$(pgrep sshd)/fd       # open file descriptors

Security-relevant /proc/sys/kernel/ parameters include dmesg_restrict, kptr_restrict, yama.ptrace_scope, and perf_event_paranoid. These should be tuned — see Chapter 13 for the complete sysctl hardening list.

Linux Audit Subsystem (auditd)¶

The auditd daemon provides kernel-level audit logging, capturing system calls, file accesses, and authentication events with cryptographic integrity (via augenrules). It writes to /var/log/audit/audit.log in a structured format.

# Install and enable auditd
apt install auditd audispd-plugins
systemctl enable --now auditd

# Watch writes to /etc/passwd
auditctl -w /etc/passwd -p wa -k passwd_changes

# Audit all execve() calls by non-root users
auditctl -a always,exit -F arch=b64 -S execve -F uid!=0 -k user_exec

# Audit privilege escalation (setuid programs)
auditctl -a always,exit -F arch=b64 -S execve -F euid=0 -F uid!=0 -k setuid_exec

The ausearch and aureport tools query the audit log:

ausearch -k passwd_changes --start today   # find passwd modification events
aureport --auth                             # authentication report
aureport --login -i                         # login report with interpreted fields

Systemd Service Sandboxing¶

Modern Linux systems use systemd to manage services. Systemd supports extensive sandboxing directives that constrain what a service can do, even if it is compromised:

# /etc/systemd/system/myapp.service
[Service]
User=myapp
Group=myapp
PrivateTmp=yes              # isolated /tmp, invisible to other services
ProtectSystem=strict        # /usr, /boot, /etc read-only
ProtectHome=yes             # /home, /root inaccessible
NoNewPrivileges=yes         # cannot gain capabilities via setuid
CapabilityBoundingSet=CAP_NET_BIND_SERVICE  # only this capability
MemoryDenyWriteExecute=yes  # no JIT / W^X bypass
LockPersonality=yes         # cannot change execution domain
RestrictSyscalls=@system-service  # syscall whitelist
ProtectKernelTunables=yes   # /proc/sys and /sys read-only
ProtectKernelModules=yes    # cannot load kernel modules
RestrictAddressFamilies=AF_INET AF_INET6  # only TCP/IP sockets

Assess a service's security posture:

systemd-analyze security nginx     # shows security score 0-10 (lower = more exposed)
systemd-analyze security --no-pager

SSH Security Hardening¶

SSH is the primary remote administration protocol for Linux. A misconfigured SSH daemon is a critical attack surface.

# /etc/ssh/sshd_config — recommended hardening settings
Protocol 2
PermitRootLogin no
PasswordAuthentication no
PubkeyAuthentication yes
AuthorizedKeysFile .ssh/authorized_keys
AllowUsers admin devops
MaxAuthTries 3
MaxSessions 5
LoginGraceTime 30
AllowTcpForwarding no
X11Forwarding no
PrintLastLog yes
Banner /etc/ssh/banner.txt

SSH Certificate Authority (CA): Instead of distributing individual public keys, an SSH CA signs user and host keys. This enables centralized revocation and greatly simplifies large-scale deployments:

# Create SSH CA key pair
ssh-keygen -t ed25519 -f /etc/ssh/ca_key -C "CorpSSH-CA"

# Sign a user key (valid 1 day, principal=admin)
ssh-keygen -s /etc/ssh/ca_key -I "john@corp" -n admin -V +1d ~/.ssh/id_ed25519.pub

# On server — trust the CA instead of individual keys
echo "TrustedUserCAKeys /etc/ssh/ca_key.pub" >> /etc/ssh/sshd_config

Linux Firewall: iptables / nftables¶

Linux uses Netfilter hooks in the kernel network stack, configured via iptables (legacy) or nftables (modern). The default-deny philosophy requires explicit rules for permitted traffic:

# nftables — default deny with allowlist
nft add table inet filter
nft add chain inet filter input { type filter hook input priority 0 \; policy drop \; }
nft add rule inet filter input ct state established,related accept
nft add rule inet filter input iif lo accept
nft add rule inet filter input tcp dport { 22, 443 } accept
nft add rule inet filter input counter drop   # log and drop everything else

OUTPUT filtering is often neglected but critical — malware on the system will attempt to call home. Restricting outbound traffic to only expected destinations limits the blast radius of a compromise.

Intrusion Detection on Linux¶

# Initialize AIDE baseline (run after clean install)
aide --init && mv /var/lib/aide/aide.db.new /var/lib/aide/aide.db

# Run daily check (add to cron)
aide --check 2>&1 | mail -s "AIDE Report $(hostname)" security@corp.com

Linux Credential Hardening¶

Configure password policy in /etc/security/pwquality.conf:

minlen = 14
dcredit = -1     # require at least 1 digit
ucredit = -1     # require at least 1 uppercase
lcredit = -1     # require at least 1 lowercase
ocredit = -1     # require at least 1 special char
maxrepeat = 3    # no more than 3 consecutive same characters

Configure account lockout in /etc/security/faillock.conf:

deny = 5           # lock after 5 failures
unlock_time = 900  # auto-unlock after 15 minutes
fail_interval = 900

Key Terms¶

Review Questions¶

1. Conceptual: Explain why the "everything is a file" design philosophy creates both convenience and security risks in Linux.
2. Conceptual: How do Linux Capabilities improve upon the traditional binary root/non-root privilege model? Give three examples of capabilities and what they permit.
3. Analytical: A developer proposes running their web application as root "to avoid permission issues." Identify at least four specific risks and explain which principle is violated.
4. Conceptual: Explain how LSM hooks differ from standard Linux DAC checks. What does "MAC stacking" mean since Linux 4.15?
5. Hands-on Lab: Configure /etc/ssh/sshd_config to disable password authentication, restrict logins to users in the sshusers group, limit MaxAuthTries to 3, and disable X11 forwarding. Test with sshd -t.
6. Hands-on Lab: Write three auditctl rules: (a) watch /etc/sudoers for any access; (b) audit all execve() calls by non-root users; (c) audit openat() on files in /etc/ssh/.
7. Conceptual: What information does /proc/PID/environ expose and under what circumstances can an attacker read another process's environment?
8. Analytical: Review this systemd service unit. Which security directives are missing that should be added for a non-privileged network service?

   [Service]
   ExecStart=/usr/bin/myapp
   User=myapp


9. Hands-on Lab: Run systemd-analyze security nginx on a Linux system. Identify three specific directives that could be added to lower the exposure level.
10. Conceptual: Compare rkhunter, AIDE, and auditd — which layer does each operate at, and can they be used together? When would each detect an intrusion?

Further Reading¶

1. The Linux Programming Interface — Michael Kerrisk (No Starch Press, 2010) — definitive reference for syscalls, /proc, and credentials
2. Red Hat: "A Guide to Linux Namespaces" — access.redhat.com
3. Linux Kernel Documentation: Documentation/admin-guide/LSM/ — kernel.org
4. NSA SELinux Project: "SELinux By Example" — Mayer, MacMillan, Caplan (Prentice Hall, 2006)
5. CIS Ubuntu Linux Benchmark — cisecurity.org (free download with registration)
